Hunter PGP-ADJ Rotor 4″ Pop-Up -
Hunter PGP-ADJ Rotor 4″ Pop-Up
The Sprinkler Nut reminds you...
- The the PGP-ADJ has a 4″ riser (the part that pops-up) with an overall body length of 7-1/2″
- All rotor heads are referenced by the height of the riser and not by the overall length of the sprinkler body
- Please note that nozzles and other replacement parts for the PGP-ADJ are not interchangeable with the PGP-04 Ultra
Categorized In:
Description
As Hunter’s original rotor, the PGP® delivers unsurpassed reliability, durability, versatility, and value.
The PGP-ADJ pgrades include a non-strippable drive and automatic arc return that allow the turret to be turned without causing damage, and return the turret to its original arc regardless of where it is turned.
Along with each rotor head you will receive a tree of 12 nozzles ranging 1 GPM to 12 GPM. We will also include a rotor adjustment tool with each order.
Please note that nozzles, set screw and other replacement parts for the PGP-ADJ are not compatible or interchangeable with the PGP-04 Ultra! For example, you will not be able to unscrew a PGP-ADJ from it’s body canister and screw it into a PGP-04 body canister, or vice-versa!
PGP-ADJ operating specifications:
- 3/4″ inlet
- Radius: 22′ to 52′
- Flow: 0.5 to 14.1 GPM
- Recommended pressure range: 25 to 70 PSI
- Operating pressure range: 20 to 100 PSI
- Precipitation rate: 0.4 in/hr (approximately)
- Nozzle trajectory = 25°
Additional Info
| Weight | 10 oz |
|---|---|
| Item Dimensions | 7-3/8" body, 1-3/4" exposed surface diameter |
| Body Length | 7-3/8" |
| Riser Height | 4 inch |
| Inlet/Outlet or Port Size | 3/4 inch |
| Connection Type | Female Thread |
| Adjustable Arc | 40-360 degrees |
| Radius | 22ft. – 52ft. |
| Min Pressure | 20 PSI |
| Max Pressure | 100 PSI |
| Manufacturer | Hunter Industries |
